FEATURES:
1、The automatic stomach lavage machine is composed of an air pump, a control pipeline, a control circuit and a case.
2、TThe stomach washing machine is controlled by pressure sensor and computer single board machine.
3、The LCD screen automatically displays the pressure of gastric lavage,in and out liquid quantity, gastric lavage condition, Gastric lavage times.
4、When in gastric lavage condition, auto access to gastric lavage and when the number of gastric lavage reaches the set number of gastric lavage, the machine stops automatically
5、Chase pipeline in and out to ensure no clogging.
6、It is equipped with the function of emergency gastric outlet. When the stomach is washed, the excess sewage can be sucked out by pressing this key.
7、Get in and out lavage pressure,the fluid volume can be arbitrarily set according to the needs of different patients.
8、Full plastic shell, beautiful and generous.
9、The absolute value of pressure is in the range of 47Kpa~67 Kpa.
10.Work Environment:temperature;+5°C～+40°C,Relative humidity:≤80%(25°C)), Atmospheric pressure:86Kpa~106 Kpa
11、According to the type and degree of electric shock prevention, the gastric lavage machine is classified into I type equipment and B type application part, The running mode is continuous operation,IPXO,Not AP type and APG type common equipments.
12、This machine meet the related requirement of IEC60601-1、IEC60601-1-2.
TECHNIQUE:
1、Power supply: AC220V±22V, 50Hz±1Hz;
2、Input:≤140VA;
3、Get into gastric pressure setting: ≤0.067MPa;
4、Get out gastric pressure setting: ≥-0.067MPa;
5、Get into gastric pressure setting:≤350ml/every time,Get out gastric pressure setting:≤450ml/every time;
6、Get in and out gastric time: ≤30s/every time.
Note: The into and out gastric fluid volume is changed according to setting value of the into and out gastric pressure.
